Product Details
Place of Origin: Shanghai, China
Brand Name: Bing Wire & Cable
Certification: CE/RoHS
Model Number: TRX316
Document: TRX316.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1000M
Price: $0.18-1.52 / foot
Delivery Time: 10-15 work days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 2000M 7 work days
|
Type:
|
Triaxial Cable
|
Conductor:
|
Silver-plated Copper
|
Insulation:
|
PTFE
|
Inner Shield:
|
Silver Plated Copper Braid
|
Inner Jacket:
|
FEP
|
Outer Shield:
|
Silver Plated Copper Braid
|
Outer Jacket:
|
FEP
|
Impedance:
|
50 Ohm
|
Temperature:
|
-55°C~+200°C
|
|
Type:
|
Triaxial Cable
|
|
Conductor:
|
Silver-plated Copper
|
|
Insulation:
|
PTFE
|
|
Inner Shield:
|
Silver Plated Copper Braid
|
|
Inner Jacket:
|
FEP
|
|
Outer Shield:
|
Silver Plated Copper Braid
|
|
Outer Jacket:
|
FEP
|
|
Impedance:
|
50 Ohm
|
|
Temperature:
|
-55°C~+200°C
|
Maximum Noise Immunity – Triaxial triple-shield design acts as an impenetrable barrier against electromagnetic interference, ensuring clean signals even when running alongside power cables.
High-Frequency Performance – Engineered for demanding 3 GHz applications, delivering consistent 50 Ohm impedance with minimal signal reflection and loss.
Extreme Environment Reliability – Built with aerospace-grade PTFE and FEP materials, this cable thrives where standard cables fail—from -55°C cold soak to +200°C oven temperatures.
Ultra-Low Noise Floor – The unique inner shield "guard" conductor actively eliminates surface leakage currents, enabling measurement of the smallest possible signals.
Flexible Yet Tough – Stranded center conductor and flexible jacket materials allow tight 28mm bend radius installation without compromising long-term durability.
Complete Shielding Protection – Dual-layer silver-plated copper braids provide comprehensive protection against both low-frequency electric fields and high-frequency RF interference.
Legacy Compatibility – Standard 3.56mm outer diameter works with existing triaxial connectors and panel mounting hardware.
Semiconductor Testing – triple-layer shielding prevents leakage that would cause false readings.
Aerospace Systems – double-braid shielding keeps signals clean for flight safety.
High-Frequency Test – 3 GHz bandwidth supports vector network analyzer connections and RF component characterization.
Medical Device Interconnects – PTFE and FEP superior shielding ensures clean data for accurate diagnosis.
Nuclear Instrumentation –radiation-resistant materials maintain stable data transmission.
Ultimate Shielding: Double silver-plated copper braid shielding maintains signal purity in complex electromagnetic environments.
Wide Temperature Stability: PTFE and FEP insulation materials ensure consistent performance from -55℃ to +200℃.
High-Frequency Compatibility: Supports operating frequencies up to 3GHz, meeting modern RF and high-speed data requirements.
Mili tary-Grade Quality: Compliant with MIL standards, with reliability and durability verified through rigorous testing.
Flexible Routing: A minimum bend radius of 25mm makes it ideal for high-density, space-constrained installations.
| Material | Diameter(mm) | |
|---|---|---|
| 1. Inner Conductor | Sliver-plated Copper Wire | 7*0.17 |
| 2. Insulation | PTFE | 1.52 |
| 3. Inner Shield | Sliver-plated Copper Wire Braid | 1.93 |
| 4. Inner Jacket | FEP | 2.44 |
| 5. Outer Shield | Sliver-plated Copper Wire Braid | 2.85 |
| 6. Outer Jacket | FEP | 3.56 |
| Capacitance(pF/m) | 96.45 |
|---|---|
| Impedance(ohm) | 50 |
| Velocity(％) | 70 |
| Minimum Bending Radius(mm) | 25 |
| Maximum Voltage(VMS) | 1200 |
| Maximum Frequency(MHz) | 3000 |
| Temperature Range(℃) | -55～+200 |
| Frequency(MHz) | Attenuation(dB/100m) |
|---|---|
| 100 | 26.2 |
| 400 | 53.1 |
| 1000 | 85.6 |
| 3000 | 153.2 |
